IMT
New Holland
TC35
Tractor
21 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 3,772 lb |
|---|---|
| Fuel Capacity | 12.7 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 3,120 lb |
| Turning Radius | 110 in |
| Alternator Supplied Amperage | 45 A |
| Operating Voltage | 12 V |
| Tire Size Front - 2wd / 4wd | 6.00-16 |
| Cooling System Fluid Capacity | 2.7 gal |
| Hydraulic System Fluid Capacity | 1.6 gal |
| Engine Oil Capacity | 8.2 gal |
Engine
| Engine Model | AD3-152 |
|---|---|
| Displacement | 153 in³ |
| Power Measured @ | 2,250 rpm |
| Gross Power | 47.0 hp |
| Number of Cylinders | 3 |
| Torque Measured @ | 1,250 rpm |
| Max Torque | 128 lb-ft |
| PTO Power | 44.0 hp |
Hydraulic System
| Pump Flow Capacity | 4.5 gal/min |
|---|---|
| Relief Valve Setting | 2,503 psi |
Dimensions
| Wheelbase | 76 in |
|---|---|
| Overall Length | 11 in |
| Overall Width | 72 in |
| Height - Top of ROPS/FOPS | 86 in |
| Height | 56 in |
Transmission
| Transmission Type | sliding spur |
|---|
Tires & Wheels
| Rear Tires Size | 13-24 |
|---|
