IMT
Massey Ferguson
4365
Tractor
Specifications pending
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Fuel Capacity | 23.8 gal |
|---|---|
| 3 Point Hitch Lift Capacity @ 24 inches | 4,910 lb |
| 3 Point Hitch Type | cat. 2 |
| Turning Radius | 150 in |
| Alternator Supplied Amperage | 45 A |
| Operating Voltage | 12 V |
| Tire Size Front - 2wd / 4wd | 7.5-16 |
| Cooling System Fluid Capacity | 3.8 gal |
| Hydraulic System Fluid Capacity | 11.4 gal |
| Engine Oil Capacity | 2.2 gal |
| Fuel Usage @ 75% Load, Full RPM | 4.10 gph (15.52 lph) |
Engine
| Engine Model | A4-248 |
|---|---|
| Displacement | 248 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 75.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 205 lb-ft |
| PTO Power | 63.4 hp |
Hydraulic System
| Pump Flow Capacity | 4.5 gal/min |
|---|---|
| Relief Valve Pressure | 3,379 psi |
| Relief Valve Setting | 3,379 psi |
Dimensions
| Height - Top of Cab | 100 in |
|---|---|
| Wheelbase | 91 in |
| Overall Length | 13 in |
| Overall Width | 81 in |
| Tire Size | front 12.4-24 rear 18.4/15-30 |
| Width Outside Frame | 81 in |
| Height - Top of ROPS/FOPS | 100 in |
| Height | 67 in |
Transmission
| Number of Forward Gears | 8 |
|---|---|
| Transmission Type | sliding spur |
| Number of Reverse Gears | 2 |
Tires & Wheels
| Rear Tires Size | 18.4/15-30 |
|---|
