Specifications
60 data points
Operating Specifications
| Operating Weight | 6,321 lb |
|---|---|
| Fuel Capacity | 14.8 gal |
| Hydraulic Pump Flow Capacity | 17.5 gal/min |
| Hydraulic System Fluid Capacity | 18.8 gal |
| Operating Voltage | 12 V |
| Engine Oil Capacity | 1.2 gal |
| Cooling System Fluid Capacity | 2.3 gal |
Engine
| Engine Model | 403D-I5 |
|---|---|
| Displacement | 91,292 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 24.7 hp |
| Net Power | 22.2 hp |
| Torque Measured @ | 1,800 rpm |
| Alternator | 65 A |
| Cooling system | Water cooled |
| Fuel | Diesel |
| Starter motor | 2.0 hp |
Hydraulic System
| Auxiliary hydraulic flow | 15.6 gal/min |
|---|---|
| Pump Type | 2 Variable & 1 Gear |
| Excavator/track main relief | 3,408 psi |
| Nominal output | 25.4 gal/min |
| Slew main relief | — |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 95 in |
| Tail Swing Radius | 49 in |
| Removal Counterweight Clearance | 30 in |
| Width Over Tracks | 60 in |
| Track Gauge | 50 in |
| Cab height | 61 in |
| Overall width of superstructure | 61 in |
| Transport Height- Minimum | 94,489 in |
| Transport Length, Minimum | 160,631 in |
Undercarriage
| Number of Track Rollers per Side | 3 |
|---|---|
| Tractive Effort | 55 lb |
| Track tension | Grease |
Boom/Stick Excavator Option 1
| Max Reach Along Ground | 183 in |
|---|---|
| Max.Dumping Height | 127 in |
| Max Digging Reach | 189 in |
| Maximum digging depth - dozer up | 108 in |
| Maximum vertical wallcut depth | 83 in |
| Maximum digging depth - dozer down | 121 in |
| Maximum height to dipper nose pivot pin | 151 in |
| Minimum front swing radius (no offset) | 81 in |
| Minimum front swing radius (fully offset) | 74 in |
Boom
| Boom swing left | 45 ° |
|---|---|
| Boom swing right | 60 ° |
| Bucket rotation | 189 ° |
| Bucket tearout | 5,171 lb |
| Dipper tearout | 3,822 lb |
| Dipper rotation | 119 ° |
| Slew speed | 10 rpm |
Blades
| Blade Width | 61 in |
|---|---|
| Blade Height | 11 in |
| Approach angle | 31 ° |
| Dig depth (below ground) | 17 in |
| Maximum height | 13 in |
| Reach in front of tracks | 15 in |
Performance
| Travel speed low | 1.6 mph |
|---|---|
| Gradeability | 36.0 % |
| Travel Speed - High | 3.1 mph |
