JCBJCB
S2632E
Aerial Lift
27 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Engine
| Engine Model | S4550E |
|---|
Hydraulic System
| system pressure | 3,481 psi |
|---|---|
| Hydraulic Oil capacity(Power angle tilt dozer) | 4.3 gal |
| Hydraulic system tank | 6.7 gal |
Dimensions
| Ground Clearance | 4 in |
|---|---|
| Weight | 7,421 lb |
| Turning Radius - Outside | 94 in |
| Solid tyre dimensions | 305 x 115 mm (12 x 4.5)in |
Brakes & Steering
| Brakes Type | 2 rear-wheel |
|---|---|
| Gradeability | 25 |
| Drive and steer model | 2 front-wheel |
Electrical System
| Battery | 12V x 4 (150) |
|---|---|
| Input voltage of Charger | 100-240 VAc |
| Output voltage of Charger | 25 A |
| Power unit | 6.1 hp |
Performance
| Load capacity | 1,554 lb |
|---|
Platform
| Max Platform Height | 544 in |
|---|---|
| Max Working Height | 612 in |
| Drive Speed - Platform Elevated | 0.5 mph |
| Drive Speed - Platform Lowered | 2.0 mph |
| Extension outreach | 36 in |
| Max allowable side force (indoor) | 90 lb-ft |
| Max allowable slope (side/side) | 2 ° |
| Max. allowable slope (front/back) | 3 ° |
| Overall height (stowed, guardrail unfolded) | 103 in |
| Overall length (stowed , guardrail folded) | 109 in |
| Overall width (stowed) | 50 in |
