JLG
Mec
2591ES
Aerial Lift
22 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Engine
| Battery Amp Hours | — |
|---|---|
| Charger Amps | 27 |
| Maximum Ground Bearing Pressure | 135 psi |
Dimensions
| Ground Clearance | 5 in |
|---|---|
| Wheelbase | 81 in |
| Overall Length | 106 in |
| Overall Width | 47 in |
| Overall Height | 101 in |
| Turning Radius | 101 in |
Brakes & Steering
| Brakes Type | Multi-Disc Friction (Hydraulic) |
|---|
Performance
| Operating Weight | 7,000 lb |
|---|---|
| Tire Size | 16 X 5 in |
| Hydraulic System Fluid Capacity | 7.9 gal |
| Gradeability | 25.0 % |
| Drive Speed - Platform Lowered | 2.0 mph |
| Drive Speed - Platform Elevated | 0.5 mph |
| Hydraulic Pump Type | Fixed Displacement Gear |
| Maximum Drive Height | 228 in |
| Drive System | Hydraulic Front Wheel |
Platform
| Max Platform Height | 56 in |
|---|---|
| Max Working Height | 544 in |
| Lift Time | 73.0 s |
| Lower Time | 48.0 s |
| Height of Rails | 46 in |
| Platform Capacity - Extension | 250 lb |
