John Deere
John Deere210LE
- Operating Weight
- 9,129 lb
- Max Speed - Forward
- 20.5 mph
- Gross Power
- 78.0 hp
- Net Power
- 73.0 hp
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 9,129 lb |
|---|---|
| Fuel Capacity | 25.9 gal |
| Cooling System Fluid Capacity | 4.3 gal |
| Tire Size | Front 12-16.5 8PR NHS Rear 16.9-24 8PR R4 |
| Hydraulic System Fluid Capacity | 14.4 gal |
| Engine Oil Fluid Capacity | 2.3 gal |
| Rear Axle Oscillation | 22 ° |
| Rear Axle/Diff Fluid Capacity | 3.5 gal |
Engine
| Engine Model | 4045D |
|---|---|
| Displacement | 276 in³ |
| Gross Power | 78.0 hp |
| Net Power | 73.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Natural |
| Torque Rise | 26.0 % |
Hydraulic System
| Pump Type | Gear |
|---|---|
| Relief Valve Setting | 2,750 psi |
| Pump Flow Capacity | 25.0 gal/min |
| Dump Time | 1.5 s |
| Lower Time | 2.4 s |
| Raise Time | 5.2 s |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 98 in |
| Wheelbase | 84 in |
| Reach at Max Lift and Dump | 35 in |
| Length with Bucket on Ground | 206 in |
| Hinge Pin - Max Height | 137 in |
Transmission
| Max Speed - Forward | 20.5 mph |
|---|---|
| Max Speed - Reverse | 20.5 mph |
| Number of Reverse Gears | 4 |
| Transmission Type | synchronized |
| Number of Forward Gears | 4 |
Bucket
| Bucket Capacity - heaped | 0.99 yd³ |
|---|---|
| Breakout Force | 7,900 lb |
| Bucket Width | 86 in |
| Dump Clearance at Max Raise | 101 in |
