B2320DTN
Tractor
39 specifications
1 / 5
Image 1 of 5
Specifications
54 data points
Engine
| Engine Model | 3TNV88C-NJT |
|---|---|
| Displacement | 100 in³ |
| Gross Power | 30.8 hp |
| Number of Cylinders | 3 |
| Aspiration | Natural |
| Stroke | 4 in |
| Bore | 4 in |
| Air cleaner | Dual element |
| Cooling system | Water pump |
| Rated Engine Speed | 2,500 rpm |
| Emissions compliance | Final Tier 4 |
| Lubrication | Pressurized |
| Fuel tank capacity | 7.6 gal |
| Cylinder liners | Cast-In-Block |
| Engine torque at rated speed | 64 lb-ft |
| Engine Manufacturer | Yanmar |
| Power take-off (PTO) power | 25.0 hp |
| Compression ratio | 19.1:1 |
| Family | EYDXL1.64NDA FYDXL1.64NDA GYDXL1.64NDA |
| Injection pump type | High pressure common rail direct injection |
Hydraulic System
| Pump Type | Dual gear |
|---|---|
| Maximum operating pressure | 2,500 psi |
| Remote control valves available | Up to two (optional) |
| Draft control sensing | Position control |
| Hydraulic Type | Open Center |
| Pump rated output | Steering - 15 L/min Implement - 20.2 L/min |
Dimensions
| Wheelbase | 754 in |
|---|---|
| Front Axle Clearance | 14 in |
| Shipping weight | 2,222 lb |
| Turning radius without brakes | 115 in |
Transmission
| Brakes | Wet disc |
|---|---|
| Steering | Power steering |
| Differential lock | Yes |
| Final Drive Type | Bull Gear |
| Cruise control | Optional |
| Axle capacity | Front - 798 kg Rear - 1197 kg |
| Standard transmission; forward/reverse | Hydrostatic transmission (HST) |
| Creeper | No |
Fluid Capacities
| Crankcase with filter | 1.2 gal |
|---|
Tires & Wheels
| Rear Tires Size | Farm - 11.2-24 Turf - 41x14-20 R4 - 15-19.5 R4 - 43x16-20 |
|---|---|
| Front Tires Size | Farm - 7-14 Turf - 27x8.5-15 R4 - 25x8.5-14 R4 - 27x8.5-15 |
Electrical System
| Alternator (12-V) | 75 A |
|---|---|
| Battery size | 500 CCA |
| Starter size | 1.9 hp |
3-Point Hitch
| Lift capacity (24-in. behind link arms) | 1,356 lb |
|---|
Power Take-Off (PTO)
| Standard | 540 rpm at 2500 rpm |
|---|---|
| Clutch | Independent |
| Control | Independent |
| Brake (for mid and rear PTO) | Wet disc |
Final Drive
| Final Drive Type | Bull Gear |
|---|
Fuel System
| Fuel System Type | High pressure common rail direct injection |
|---|
Operator Station
| Gear shift location - console/floor | Left Hand Side |
|---|---|
| Platform - flat/straddle | Semi-flat |
| Rollover protective structure | Foldable ASABE S478 |
