John Deere
Massey Ferguson
4365
Tractor
Specifications pending
1 / 5
Image 1 of 5
Specifications
61 data points
Engine
| Engine Model | 3TNV86CHT-MJT |
|---|---|
| Displacement | 96 in³ |
| Gross Power | 44.7 hp |
| Number of Cylinders | 3 |
| Aspiration | Turbocharged and charge air cooled |
| Stroke | 4 in |
| Bore | 3 in |
| Engine Type | Diesel |
| Air cleaner | Dual element with electronic restriction indicator |
| Cooling system | Water pump |
| Rated Engine Speed | 2,600 rpm |
| Emissions compliance | Final Tier 4 |
| Lubrication | Pressurized |
| Fuel tank capacity | — |
| Compression ratio | 19.1:1 |
| Cylinder liners | Cast-In-Block |
| Engine Manufacturer | Yanmar |
| Engine torque at rated speed | 83 lb-ft |
| Power take-off (PTO) power | 36.6 hp |
| Family | EYDXL1.57HDA FYDXL1.57HDA GYDXL1.57HDA |
| Injection pump type | High pressure common rail direct injection |
Hydraulic System
| Pump Type | Dual gear |
|---|---|
| Maximum operating pressure | 2,500 psi |
| Remote control valves available | Up to four rear remotes |
| Draft control sensing | Position control |
| Hydraulic Type | Open Center |
| Pump rated output | Steering - 22.3 L/min Implement - 32.5 L/min |
Dimensions
| Wheelbase | 816 in |
|---|---|
| Front Axle Clearance | 12 in |
| Turning radius with brakes | 106 in |
| Approximate shipping weight (open-station; cab) | ROPS - 1315.4 kg Cab - 1619.3 kg |
Transmission
| Brakes | Multi-plate wet disc |
|---|---|
| Steering | Hydrostatic power steering |
| Final Drive Type | Bull Gear |
| Cruise control | Standard |
| Axle capacity | Front - 720-1450 kg |
| Standard transmission; forward/reverse | Gear 4WD / eHydro (electronic hydrostatic) |
| Creeper | SpeedMatch optional |
| Transmission gear ranges | 12F/12R PowrReverser (PRT) Infinitely variable - 3 range |
Fluid Capacities
| Crankcase with filter | 1.5 gal |
|---|---|
| Transmission and hydraulic system | 6.8 gal |
Tires & Wheels
| Rear Tires Size | Farm - 11.2-24 Turf - 41x14-20 or 41x18LL-16.1 R4 - 15-19.5 |
|---|---|
| Front Tires Size | Farm - 7-14 Turf (Gear 4WD) - 27x8.50-15 Turf (HST 4WD) - 25x10.5LLx15 R4 - 25x8.5-14 |
| Front tread range | 45 in |
| Rear tread spacing | 41 in |
Electrical System
| Alternator (12-V) | 75 A |
|---|---|
| Battery size | 500 CCA |
| Starter size | 1.9 hp |
3-Point Hitch
| Lift capacity (24-in. behind link arms) | 2,200 lb |
|---|
Power Take-Off (PTO)
| Optional | Mid - 2000 rpm |
|---|---|
| Standard | Rear - 540 rpm |
| Clutch | Multiple wet disc |
| Control | Position control |
| Brake (for mid and rear PTO) | Multiple wet disc |
| Engagement method | Electro-hydraulic |
Final Drive
| Final Drive Type | Bull Gear |
|---|
Fuel System
| Fuel System Type | High pressure common rail direct injection |
|---|---|
| Fuel consumption | 10.6 L/hr |
Operator Station
| Gear shift location - console/floor | Left Hand Side |
|---|---|
| Platform - flat/straddle | Flat |
| Rollover protective structure | Type Foldable Yes |
Comparable machines
Other tractors in a similar weight class.
