John Deere
Hesston
946 Auto-Cycle
Baler
20 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Dimensions
| Overall Length | 228 in |
|---|---|
| Overall Width | 108 in |
| Overall Height | 67 in |
| Weight | 2,804 lb |
| Tractor PTO Power Required | 35.0 hp |
Bale Size
| Bale Width | 19 in |
|---|---|
| Bale Length - max | 50 in |
| Bale Height | 15 in |
| Bale Length - min | 13 in |
Baler Pickup
| Overall Width | 74 in |
|---|---|
| Number of Bars | 6 |
| Tine to Tine Width | 64 in |
| Number of Tines | 156 |
| Lift Type | crank |
Feeding Chamber
| Feed Opening | 295 in³ |
|---|
Plunger
| SPM | 80 |
|---|---|
| Stroke Length | 30 in |
| Bearing Type | sealed ball-bearing rollers |
Wrapping System
| Twine Ball Capacity | 8 |
|---|---|
| Twine Type | plastic or sisal |
| Wire Coil Capacity | 4 |
