D31PG-20A
Crawler Loader
15 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 12,400 lb |
|---|---|
| Fuel Capacity | 22.0 gal |
| Cooling System Fluid Capacity | 3.3 gal |
| Hydraulic System Fluid Capacity | 6.4 gal |
| Final Drive Fluid Capacity - each | 10.0 gal |
| Engine Oil Capacity | 2.3 gal |
Engine
| Engine Model | 300 Series |
|---|---|
| Displacement | 164 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 42.0 hp |
| Number of Cylinders | 3 |
| Aspiration | Naturally aspirated |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 110 lb-ft |
Hydraulic System
| Pump Flow Capacity | 14.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,250 psi |
| Pump Type | Open Center |
Dimensions
| Width to Outside of Tracks | 72 in |
|---|
