John Deere
Mitsubishi
BD2HS-HB1
Crawler Dozer
17 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 11,820 lb |
|---|---|
| Fuel Capacity | 31.0 gal |
| Cooling System Fluid Capacity | 3.3 gal |
| Final Drives Fluid Capacity | 14.0 gal |
| Hydraulic Fluid Capacity | 8.5 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 A |
Engine
| Engine Model | 4039D |
|---|---|
| Displacement | 239 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 63.0 hp |
| Net Power | 60.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 188 lb-ft |
Hydraulic System
| Pump Flow Capacity | 11.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,750 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Length of Track on Ground | 78 in |
| Length w/o Blade | 144 in |
Transmission
| Max Speed - Forward | 6.2 mph |
|---|---|
| Max Speed - Reverse | 5.9 mph |
| Transmission Type | Hi-Lo-Reverse with direct drive |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Number of Track Rollers per Side | 5 |
| Number of Shoes per Side | 36 |
| Standard Shoe Size | 14 in |
| Ground Contact Area | 1,940 in³ |
| Track Pitch | 50 in |
Standard Blade
| Width | 90 in |
|---|---|
| Height | 29 in |
| Capacity | 1.10 yd³ |
| Blade Angle (both directions) | 50 ° |
