John Deere
Massey Ferguson
4365
Tractor
Specifications pending
1 / 5
Image 1 of 5
Specifications
64 data points
Engine
| Engine Model | 4TNV88C-MJT |
|---|---|
| Displacement | 134 in³ |
| Gross Power | 31.7 hp |
| Number of Cylinders | 4 |
| Aspiration | Natural |
| Stroke | 4 in |
| Bore | 4 in |
| Engine Type | Diesel |
| Air cleaner | Dual element with electronic restriction indicator |
| Cooling system | Liquid |
| Rated Engine Speed | 2,600 rpm |
| Emissions compliance | Final Tier 4 |
| Lubrication | Pressurized |
| Fuel tank capacity | — |
| Cylinder liners | Cast-In-Block |
| Engine Manufacturer | Yanmar |
| Engine torque at rated speed | 86 lb-ft |
| Compression ratio | 19.1:1 |
| Family | EYDXL2.19NDA FYDXL2.19NDA GYDXL2.19NDA |
| Power take-off (PTO) power | 34.5 hp |
Hydraulic System
| Pump Type | High pressure common rail direct injection |
|---|---|
| Remote control valves available | Three remotes optional |
| Draft control sensing | Position control |
| Hydraulic Type | Open Center |
| Pump rated output | Steering Hydrostatic power steering 60.2 L/min 15.9 gpm |
Dimensions
| Wheelbase | 876 in |
|---|---|
| Front Axle Clearance | 16 in |
| Turning radius with brakes | 110 in |
| Turning radius without brakes | 119 in |
| Approximate shipping weight (open-station; cab) | OOS - 1710 kg 3770 lb Cab - 2120 kg 4675 lb |
Transmission
| Brakes | Multi-plate wet disc |
|---|---|
| Steering | Hydrostatic power steering |
| Clutch, wet/dry | Wet |
| Differential lock | Yes |
| Final Drive Type | Planetary |
| Cruise control | Standard |
| Axle capacity | Front 1600 kg 3528 lbRear 2400 kg 5292 lb Mechanical front-wheel drive (MFWD) - 1.6 kg 5.9 lb |
| Standard transmission; forward/reverse | 12/12 PowrReverser transmission (PRT) |
| Creeper | Standard |
| Left-hand reverser | Yes |
| Clutch disk diameter wet clutch | 5 in |
| Optional transmission; forward/reverse | 3/3 Hydrostatic transmission (HST) |
| Transmission gear ranges | 12F/12R PRT Infinitely-variable 3 range |
Fluid Capacities
| Crankcase with filter | 1.4 gal |
|---|---|
| Transmission and hydraulic system | 11.6 gal |
Tires & Wheels
| Rear Tires Size | Farm - 13.6-28 Turf - 44x18-20 or 22.5LL-16.1 R4 - 16.9Lx24 |
|---|---|
| Front Tires Size | Farm - 8-16 Turf - 27x10.5-15 or 27x12LL-15 R4 - 10-16.5 |
| Front tread range | 58 in |
| Rear tread spacing | 54 in |
Electrical System
| Alternator (12-V) | 75 A |
|---|---|
| Battery size | 770 CCA |
| Starter size | 2.7 hp |
3-Point Hitch
| Lift capacity (24-in. behind link arms) | 2,502 lb |
|---|
Power Take-Off (PTO)
| Optional | 540 rpm 540E rpm |
|---|---|
| Standard | Independent 540 rpm at 2600 rpm |
| Clutch | Wet disc |
| Control | Position |
| Engagement method | Electro-hydraulic |
Final Drive
| Final Drive Type | Planetary |
|---|---|
| Differential lock | Yes |
Fuel System
| Fuel System Type | High pressure common rail direct injection |
|---|
Operator Station
| Gear shift location - console/floor | Left Hand Side |
|---|---|
| Platform - flat/straddle | Flat |
| Rollover protective structure | Type Foldable Yes |
