John Deere
Hesston
740
Baler
17 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Dimensions
| Overall Length | 135 in |
|---|---|
| Overall Width | 90 in |
| Overall Height | 93 in |
| Weight | 3,360 lb |
| Tractor PTO Power Required | 45.0 hp |
Bale Size
| Bale Width | 47 in |
|---|---|
| Bale Diameter - max | 52 in |
| Bale Diameter - min | 36 in |
| Bale Weight - max | 1,250 lb |
| Bale Weight - min | 750 lb |
Baler Pickup
| Overall Width | 56 in |
|---|---|
| Number of Bars | 4 |
| Tine to Tine Width | 47 in |
| Number of Tines | 72 |
| Lift Type | crank |
Wrapping System
| Twine Ball Capacity | 5 |
|---|---|
| Twine Type | hydraulic |
Bale Chamber
| Number of Belts | 6 |
|---|---|
| Belt Width | 7 in |
