John Deere
Mitsubishi
BD2FS-1B6
Crawler Dozer
16 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 15,630 lb |
|---|---|
| Fuel Capacity | 31.0 gal |
| Cooling System Fluid Capacity | 4.0 gal |
| Final Drives Fluid Capacity | 1.6 gal |
| Engine Oil Capacity | 2.3 gal |
| Hydraulic Fluid Capacity | 7.0 gal |
| Operating Voltage | 12 V |
Engine
| Engine Model | 300 Series |
|---|---|
| Displacement | 202 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 57.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Naturally asprated or turbocharged |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 145 lb-ft |
Hydraulic System
| Pump Flow Capacity | 14.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,250 psi |
| Pump Type | Open Center |
Dimensions
| Width Over Tracks | 66 in |
|---|
Transmission
| Transmission Type | HLR:4 speed ranges with high low and reverse |
|---|---|
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
