John Deere
Mitsubishi
BD2FSS-1B2
Crawler Dozer
17 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 14,500 lb |
|---|---|
| Fuel Capacity | 31.0 gal |
| Cooling System Fluid Capacity | 4.0 gal |
| Final Drives Fluid Capacity | 1.6 gal |
| Engine Oil Capacity | 2.3 gal |
| Hydraulic Fluid Capacity | 8.0 gal |
| Hydraulic System Fluid Capacity | 13.0 gal |
| Final Drive Fluid Capacity - each | 1.6 gal |
Engine
| Engine Model | 300 Series |
|---|---|
| Displacement | 219 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 65.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Naturally aspirated |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 178 lb-ft |
Hydraulic System
| Pump Flow Capacity | 14.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,250 psi |
| Pump Type | Open-center |
Dimensions
| Width to Outside of Tracks | 72 in |
|---|---|
| Width Over Tracks | 72 in |
Transmission
| Transmission Type | HLR: 4 speed ranges |
|---|
