John Deere
Furukawa
FD40-1
Crawler Dozer
21 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 14,400 lb |
|---|---|
| Fuel Capacity | 31.0 gal |
| Cooling System Fluid Capacity | 4.0 gal |
| Final Drives Fluid Capacity | 1.6 gal |
| Engine Oil Capacity | 2.3 gal |
| Hydraulic Fluid Capacity | 7.0 gal |
| Operating Voltage | 12 V |
Engine
| Engine Model | 300 Series |
|---|---|
| Displacement | 219 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 67.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 190 lb-ft |
Hydraulic System
| Pump Flow Capacity | 17.1 gal/min |
|---|---|
| Relief Valve Pressure | 2,000 psi |
| Pump Type | Open Center |
Dimensions
| Width Over Tracks | 90 in |
|---|
Transmission
| Transmission Type | HLR:4 speed ranges with high low and reverse |
|---|---|
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
