John Deere
Hyster
H40FT
Forklift
39 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 12,510 lb |
|---|---|
| Max Speed | 24.2 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
Engine
| Engine Model | 4045D |
|---|---|
| Displacement | 276 in³ |
| Power Measured @ | 2,200 rpm |
| Number of Cylinders | 4 |
| Power | 73.0 hp |
| Torque | 220 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 84 in |
| Overall Width | 86 in |
| Turning Radius | 132 in |
| Overall Height - mast lowered | 121 in |
| Length to Fork Face | 150 in |
| Height to Top of Overhead Guard | 102 in |
| Max Fork Height | 200 in |
Mast
| Load Capacity | 6,000 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.1 mph |
| Mast Tip Forward | 30 ° |
| Mast Tip Rear | 10 ° |
