John Deere
Mitsubishi
BD2HS-HB1
Crawler Dozer
17 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Fuel Capacity | 41.0 gal |
|---|---|
| Cooling System Fluid Capacity | 4.5 gal |
| Final Drives Fluid Capacity | 2.6 gal |
| Engine Oil Capacity | 3.3 gal |
| Hydraulic Fluid Capacity | 10.0 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 A |
Engine
| Engine Model | 4045D |
|---|---|
| Displacement | 276 in³ |
| Gross Power | 99.0 hp |
| Net Power | 90.0 hp |
| Aspiration | Naturally aspirated direct drive |
Hydraulic System
| Pump Flow Capacity | 17.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,750 psi |
| Pump Type | Gear |
Dimensions
| Height - Top of Cab | 110 in |
|---|---|
| Length w/o Blade | 161 in |
Transmission
| Max Speed - Forward | 5.6 mph |
|---|---|
| Max Speed - Reverse | 6.2 mph |
| Transmission Type | Full power shift Dura-Shift with direct drive |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Undercarriage
| Track Pitch | 7 in |
|---|
Standard Blade
| Width | 106 in |
|---|---|
| Height | 35 in |
| Capacity | 2.50 yd³ |
| Blade Angle (both directions) | 25 ° |
