973C WH
Crawler Loader
14 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 46,300 lb |
|---|---|
| Bucket Capacity - heaped | 3.20 yd³ |
| Max Speed | 6.8 mph |
| Fuel Capacity | 84.5 gal |
| Static Tipping Load | 30,413 lb |
| Breakout Force Bucket | 37,080 lb |
| Cooling System Fluid Capacity | 15.3 gal |
| Hydraulic System Fluid Capacity | 46.2 gal |
| Final Drive Fluid Capacity - each | 18.0 gal |
| Engine Oil Capacity | 5.8 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 A |
Engine
| Engine Model | D 926 T-EA2 |
|---|---|
| Displacement | 610 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 177.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,000 rpm |
| Max Torque | 678 lb-ft |
Hydraulic System
| Pump Flow Capacity | 55.0 gal/min |
|---|---|
| Lower Time | 1.5 s |
| Raise Time | 6.5 s |
| Relief Valve Pressure | 3,770 psi |
| Dump Time | 2.1 s |
| Pump Type | Variable-Displacement piston pump with load-sensing proportional pump flow control |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 131 in |
| Width to Outside of Tracks | 91 in |
| Length with Bucket on Ground | 270 in |
| Clearance at Full Height and Dump | 122 in |
| Reach at Dump Height | 48 in |
| Length to Front of Track | 190 in |
Undercarriage
| Length of Track on Ground | 106 in |
|---|---|
| Track Gauge | 71 in |
| Track Shoe Width | 20 in |
| Ground Pressure | 11 psi |
| Number of Track Rollers per Side | 6 |
| Ground Contact Area | 4,210 in³ |
| Number of Shoes per Side | 39 |
