John Deere
8570
- Operating Weight
- 32,099 lb
- Displacement
- 464 in³
- Power Measured @
- 2,100 rpm
- Gross Power
- 250.0 hp
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 32,099 lb |
|---|---|
| Fuel Capacity | 220.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 14,980 lb |
| 3 Point Hitch Type | III |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 14.6 gal |
| Hydraulic System Fluid Capacity | 38.0 gal |
| Engine Oil Capacity | 6.1 gal |
| Front Tire Size | 24.5R-32 |
| Rear Tire Size | 24.5R-32 |
Engine
| Displacement | 464 in³ |
|---|---|
| Power Measured @ | 2,100 rpm |
| Gross Power | 250.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Engine Make | John Deere |
| PTO Power | 205.0 hp |
| Stroke | 5 in |
| Bore | 5 in |
Hydraulic System
| Pump Flow Capacity | 44.8 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Relief Valve Pressure | 2,530 psi |
| Hydraulic System Type | Closed-center pressure compensated |
Dimensions
| Wheelbase | 134 in |
|---|---|
| Overall Length | 269 in |
| Front Axle Clearance | 120 in |
| Shipping weight | 29,564 lb |
| Rear axle clearance | 120 in |
Transmission
| Number of Forward Gears | 12 |
|---|---|
| Transmission Type | Partially synchronized |
| Number of Reverse Gears | 3 |
