Specifications
47 data points
Operating Specifications
| Operating Weight | 18,821 lb |
|---|---|
| Alternator Supplied Amperage | 50 A |
| Fuel Capacity | 35.7 gal |
| Hydraulic System Fluid Capacity | 27.3 gal |
| Operating Voltage | 24 V |
| Cooling System Fluid Capacity | 2.8 gal |
| Engine Oil Capacity | 3.2 gal |
| Hydraulic Pump Flow Capacity | 58.2 gal/min |
| Hydraulic System Relief Valve Pressure | 4,554 psi |
Engine
| Engine Model | 4LE2X Tier IIII certified |
|---|---|
| Displacement | 133 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 54.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged intercooler |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 107 in |
| Tail Swing Radius | 59 in |
| Width to Outside of Tracks | 98 in |
| Removal Counterweight Clearance | 30 in |
Undercarriage
| Max Travel Speed | 3.2 mph |
|---|---|
| Shoe Size | 24 in |
| Ground Pressure | 4 psi |
| Track Gauge | 74 in |
| Number of Track Rollers per Side | 5 |
| Drawbar Pull | 14,661 lb |
| Number of Carrier Rollers per Side | 1 |
| Number of Shoes per Side | 40 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 157 in |
|---|---|
| Max Loading Height | 190 in |
| Max Reach Along Ground | 278 in |
| Max Vertical Wall Digging Depth | 137 in |
| Shipping Height of Unit | 107 in |
| Shipping Length of Unit | 264 in |
| Max Cutting Height | 269 in |
Bucket
| Reference Bucket Capacity | 0.60 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.71 yd³ |
| Minimum Bucket Capacity | 0.50 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|---|
| Swing Torque | 12,244 lb-ft |
Boom/Stick Excavator Option 2
| Max Digging Depth | 176 in |
|---|---|
| Max Cutting Height | 283 in |
| Max Loading Height | 203 in |
| Max Reach Along Ground | 298 in |
| Max Vertical Wall Digging Depth | 159 in |
| Shipping Height of Unit | 107 in |
| Shipping Length of Unit | 269 in |
