John DeereJohn Deere
8RT 335
Tractor
17 specifications
John Deere
8970
- Operating Weight
- 33,655 lb
- Displacement
- 854 in³
- Power Measured @
- 2,100 rpm
- Gross Power
- 400.0 hp
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 33,655 lb |
|---|---|
| Fuel Capacity | 220.0 gal |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 18.0 gal |
| Hydraulic System Fluid Capacity | 38.0 gal |
| Engine Oil Capacity | 9.1 gal |
| Front Tire Size | 24.5R-32 |
| Rear Tire Size | 24.5R-32 |
Engine
| Displacement | 854 in³ |
|---|---|
| Power Measured @ | 2,100 rpm |
| Gross Power | 400.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Engine Make | John Deere |
| PTO Power | 339.0 hp |
| Stroke | 6 in |
| Bore | 6 in |
Hydraulic System
| Pump Flow Capacity | 38.0 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Relief Valve Pressure | 2,530 psi |
| Hydraulic System Type | Closed-center pressure compensated |
Dimensions
| Wheelbase | 134 in |
|---|---|
| Overall Length | 269 in |
| Front Axle Clearance | 128 in |
| Shipping weight | 31,879 lb |
| Rear axle clearance | 128 in |
Transmission
| Number of Forward Gears | 12 |
|---|---|
| Transmission Type | Partially synchronized |
| Number of Reverse Gears | 3 |
