TC35
Tractor
21 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 3,728 lb |
|---|---|
| Fuel Capacity | 11.9 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,383 lb |
| 3 Point Hitch Type | Cat I |
| Turning Radius | 113 in |
Engine
| Engine Model | 3B183LWM |
|---|---|
| Displacement | 112 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 38.0 hp |
| Number of Cylinders | 3 |
| PTO Power | 28.5 hp |
Hydraulic System
| Pump Flow Capacity | 15.3 gal/min |
|---|
Dimensions
| Ground Clearance | 14 in |
|---|---|
| Height - Top of Cab | 94 in |
| Wheelbase | 70 in |
| Overall Length | 11 in |
| Tire Size | front 7-16/6 rear 12.4-24/6 |
| Width Outside Frame | 62 in |
Transmission
| Max Speed | 14.6 mph |
|---|---|
| Number of Forward Gears | 12 |
| Transmission Type | synchro shuttle |
| Number of Reverse Gears | 12 |
