209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 3,922 lb |
|---|---|
| Fuel Capacity | 11.9 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,493 lb |
| 3 Point Hitch Type | Cat I |
| Turning Radius | 115 in |
Engine
| Engine Model | 4A200LWM |
|---|---|
| Displacement | 122 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 41.0 hp |
| Number of Cylinders | 4 |
| PTO Power | 34.0 hp |
Hydraulic System
| Pump Flow Capacity | 16.9 gal/min |
|---|---|
| Number of Remote Control Valves | 1 |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 96 in |
| Wheelbase | 74 in |
| Overall Length | 11 in |
| Tire Size | front 8-16/6 rear 13.6-24/6 |
| Width Outside Frame | 65 in |
Transmission
| Max Speed | 15.3 mph |
|---|---|
| Number of Forward Gears | 12 |
| Transmission Type | synchro shuttle |
| Number of Reverse Gears | 12 |
