Kioti
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 5,181 lb |
|---|---|
| Fuel Capacity | 18.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,654 lb |
| 3 Point Hitch Type | Cat. II |
| Turning Radius | 115 in |
Engine
| Engine Model | 4A220T |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 54.0 hp |
| Number of Cylinders | 4 |
| PTO Power | 45.2 hp |
Hydraulic System
| Pump Flow Capacity | 9.9 gal/min |
|---|
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 97 in |
| Wheelbase | 76 in |
| Overall Length | 11 in |
| Tire Size | front 9.5-20 rear 14.9-28 |
| Width Outside Frame | 70 in |
Transmission
| Max Speed | 17.3 mph |
|---|---|
| Number of Forward Gears | 12 |
| Transmission Type | synchro shuttle |
| Number of Reverse Gears | 12 |
