Kioti
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 6,856 lb |
|---|---|
| Fuel Capacity | 26.5 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 4,850 lb |
| 3 Point Hitch Type | Cat. II |
| Turning Radius | 131 in |
Engine
| Engine Model | 1103C-33T |
|---|---|
| Displacement | 201 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 64.0 hp |
| Number of Cylinders | 3 |
| PTO Power | 55.0 hp |
Hydraulic System
| Pump Flow Capacity | 10.9 gal/min |
|---|---|
| Number of Remote Control Valves | 2 |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 104 in |
| Wheelbase | 81 in |
| Overall Length | 12 in |
| Tire Size | FRONT 9.5X24 REAR 16.9-30 |
| Width Outside Frame | 70 in |
Transmission
| Max Speed | 18.6 mph |
|---|---|
| Number of Forward Gears | 12 |
| Transmission Type | synchro shuttle |
| Number of Reverse Gears | 12 |
