Kobelco
Liebherr
LR-1110
Crawler Crane
Specifications pending
1 / 5
Image 1 of 5
Specifications
27 data points
Engine
| Engine Model | P11C-VN |
|---|---|
| Displacement | 469 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 365.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 1,084 lb-ft |
| Stroke | 6 in |
| Bore | 5 in |
| Alternator | 80 A |
| Emission Tier Level | Tire 4 Final |
| Air cleaner | Dry type with replaceable paper element |
| Starter | 8.1 hp |
| Fuel Filter | Replaceable element |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Overall Width | 263 in |
| Gradeability | 40.0 % |
| Counterweight Clearance | 54 in |
| Shoe width | 576 in |
| Center to center - idler to sprocket | 56 in |
| Overall length of crawler | 302 in |
Boom
| Boom Length | 480 in |
|---|---|
| Basic jib length | 1,182 in |
| Boom base section | 300 in |
| Boom tip section | 300 in |
| Jib base section | 181 in |
| Jib tip section | 181 in |
Comparable machines
Other crawler cranes in a similar weight class.
