Komatsu
Mitsubishi
BD2HS-HB1
Crawler Dozer
17 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 9,350 lb |
|---|---|
| Fuel Capacity | 15.9 gal |
| Cooling System Fluid Capacity | 2.6 gal |
| Final Drives Fluid Capacity | 2.1 gal |
| Engine Oil Capacity | 1.7 gal |
| Hydraulic Fluid Capacity | 5.5 gal |
Engine
| Engine Model | 4D94LE-2 |
|---|---|
| Displacement | 186 in³ |
| Gross Power | 43.1 hp |
| Net Power | 40.0 hp |
| Number of Cylinders | 4 |
| Aspiration | naturally aspirated |
| Make | Komatsu |
Dimensions
| Height - Top of Cab | 97 in |
|---|---|
| Width Over Tracks | 60 in |
| Length w/ Blade | 133 in |
Transmission
| Max Speed - Forward | 2.7 mph |
|---|---|
| Max Speed - Reverse | 3.5 mph |
| Transmission Type | Komatsu HYDROSHIFT transmission |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Undercarriage
| Ground Pressure | 3 psi |
|---|---|
| Number of Track Rollers per Side | 5 |
| Number of Shoes per Side | 37 |
| Standard Shoe Size | 20 in |
| Ground Contact Area | 2,664 in³ |
Standard Blade
| Width | 102 in |
|---|---|
| Height | 3 in |
| Capacity | 24.99 yd³ |
| Blade Angle (both directions) | 25 ° |
