Komatsu
Mitsubishi
BD2HS-HB1
Crawler Dozer
17 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 12,015 lb |
|---|---|
| Fuel Capacity | 30.4 gal |
| Cooling System Fluid Capacity | 5.9 gal |
| Final Drives Fluid Capacity | 3.2 gal |
| Engine Oil Capacity | 3.2 gal |
Engine
| Engine Model | S4D102E |
|---|---|
| Displacement | 239 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 80.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Hydraulic System
| Relief Valve Pressure | 3 psi |
|---|---|
| Pump Type | gear type |
Transmission
| Max Speed - Forward | 4.3 mph |
|---|---|
| Max Speed - Reverse | 4.7 mph |
| Transmission Type | hydroshift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 57 in |
| Number of Track Rollers per Side | 6 |
| Number of Shoes per Side | 41 |
| Standard Shoe Size | 13 in |
| Ground Contact Area | 2,235 in³ |
