Komatsu
Caterpillar
D3K LGP
Crawler Dozer
35 specifications
:quality(50)/73871/conversions/a758d5c3-0944-4a5c-80c3-5cc73bfbb2d1-thumb.webp)
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 21,605 lb |
|---|---|
| Fuel Capacity | 64.8 gal |
| Cooling System Fluid Capacity | 8.8 gal |
Engine
| Engine Model | 6D105-1 |
|---|---|
| Displacement | 396 in³ |
| Power Measured @ | 2,350 rpm |
| Gross Power | 93.0 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 110 in |
| Length of Track on Ground | 81 in |
| Width Over Tracks | 77 in |
| Length w/ Blade | 168 in |
| Length w/o Blade | 134 in |
Transmission
| Max Speed - Forward | 5.5 mph |
|---|---|
| Max Speed - Reverse | 5.0 mph |
| Transmission Type | DD |
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 4 |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 61 in |
| Number of Track Rollers per Side | 5 |
| Number of Shoes per Side | 37 |
| Number of Carrier Rollers per Side | 1 |
| Standard Shoe Size | 16 in |
| Track Pitch | 7 in |
Standard Blade
| Width | 126 in |
|---|---|
| Height | 30 in |
