D3K LGP
Crawler Dozer
35 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 23,369 lb |
|---|
Engine
| Engine Model | 6D105-1 |
|---|---|
| Displacement | 397 in³ |
| Power Measured @ | 2,350 rpm |
| Gross Power | 95.0 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 110 in |
| Length of Track on Ground | 89 in |
| Width Over Tracks | 85 in |
| Length w/ Blade | 176 in |
| Length w/o Blade | 134 in |
Transmission
| Transmission Type | DD |
|---|---|
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 4 |
Undercarriage
| Track Gauge | 70 in |
|---|---|
| Number of Track Rollers per Side | 6 |
| Number of Shoes per Side | 39 |
| Number of Carrier Rollers per Side | 1 |
| Standard Shoe Size | 16 in |
| Track Pitch | 7 in |
Standard Blade
| Width | 108 in |
|---|---|
| Height | 36 in |
