Komatsu
Case
650K LT
Crawler Dozer
48 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 30,181 lb |
|---|---|
| Fuel Capacity | 84.6 gal |
| Cooling System Fluid Capacity | 16.7 gal |
Engine
| Engine Model | NH220-CI |
|---|---|
| Displacement | 743 in³ |
| Gross Power | 165.0 hp |
Dimensions
| Height - Top of Cab | 119 in |
|---|---|
| Length of Track on Ground | 104 in |
| Width Over Tracks | 95 in |
| Length w/o Blade | 211 in |
Transmission
| Max Speed - Forward | 6.8 mph |
|---|---|
| Max Speed - Reverse | 8.6 mph |
| Transmission Type | planetary gear |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 74 in |
| Number of Track Rollers per Side | 7 |
| Standard Shoe Size | 20 in |
Standard Blade
| Width | 157 in |
|---|---|
| Height | 41 in |
