Komatsu

FD40PL-1

Crawler Dozer

Operating Weight
9,745 lb
Gross Power
40.0 hp
All crawler dozers
Komatsu FD40PL-1 Crawler Dozer
1 / 5
Image 1 of 5
Image: purplewave.com

Specifications

23 data points

Operating Specifications

Operating Specifications specifications
Operating Weight9,745 lb

Engine

Engine specifications
Engine ModelA-4JG2
Displacement187 in³
Power Measured @2,200 rpm
Gross Power40.0 hp
Number of Cylinders4

Dimensions

Dimensions specifications
Ground Clearance13 in
Height - Top of Cab98 in
Length of Track on Ground74 in
Width Over Tracks86 in
Length w/ Blade139 in
Length w/o Blade103 in

Transmission

Transmission specifications
Transmission TypeDD
Number of Forward Gears3
Number of Reverse Gears2

Undercarriage

Undercarriage specifications
Track Gauge59 in
Number of Track Rollers per Side6
Number of Shoes per Side60
Number of Carrier Rollers per Side1
Standard Shoe Size28 in
Track Pitch5 in

Standard Blade

Standard Blade specifications
Width98 in
Height24 in
