Komatsu

FD45P-1

Crawler Dozer

Operating Weight
9,546 lb
Gross Power
40.0 hp
All crawler dozers
Komatsu FD45P-1 Crawler Dozer
1 / 5
Image 1 of 5
Image: komatsu.com

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight9,546 lb

Engine

Engine specifications
Engine ModelA-4JG2
Displacement187 in³
Power Measured @2,200 rpm
Gross Power40.0 hp
Number of Cylinders4

Dimensions

Dimensions specifications
Ground Clearance13 in
Height - Top of Cab98 in
Length of Track on Ground67 in
Width Over Tracks79 in
Length w/ Blade138 in
Length w/o Blade96 in

Transmission

Transmission specifications
Transmission TypeDD
Number of Forward Gears3
Number of Reverse Gears3

Undercarriage

Undercarriage specifications
Track Gauge59 in
Number of Track Rollers per Side5
Number of Carrier Rollers per Side1
Standard Shoe Size20 in
Track Pitch5 in

Standard Blade

Standard Blade specifications
Width101 in
Height24 in
