Komatsu
John Deere
JD380
Forklift
23 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 14,780 lb |
|---|---|
| Max Speed | 9.6 mph |
| Number of Front Wheels | 4 |
| Number of Rear Wheels | 2 |
| Tire Type | Cushion |
Engine
| Engine Model | TB45E |
|---|---|
| Displacement | 273 in³ |
| Power Measured @ | 2,400 rpm |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,600 rpm |
| Power | 95.0 hp |
| Fuel Type | Gasoline |
| Torque | 203 lb-ft |
Dimensions
| Ground Clearance | 5 in |
|---|---|
| Wheelbase | 64 in |
| Overall Width | 54 in |
| Turning Radius | 95 in |
| Overall Height - mast lowered | 96 in |
| Length to Fork Face | 109 in |
| Height to Top of Overhead Guard | 84 in |
| Max Fork Height | 131 in |
| Right Angle Stack | 113 in |
Mast
| Load Capacity | 10,000 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.1 mph |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 6 ° |
| Lower Speed | 1.1 mph |
| Number of Mast Sections | 2 |
