Komatsu
Daewoo
SOLAR 130LC V
Excavator
3 specifications
Komatsu
PC210LC-11
- Operating Weight
- 50,089 lb
- Max Digging Depth
- 240 in
- Max Digging Depth
- 261 in
- Net Power
- 165.0 hp
1 / 5
Image 1 of 5
Specifications
59 data points
Operating Specifications
| Operating Weight | 50,089 lb |
|---|---|
| Fuel Capacity | 105.7 gal |
| Hydraulic Pump Flow Capacity | 125.5 gal/min |
| Hydraulic System Fluid Capacity | 34.9 gal |
| Engine Oil Capacity | 6.2 gal |
| Swing Drive Fluid Capacity | 1.8 gal |
Engine
| Engine Model | SAA6D107E-3 |
|---|---|
| Displacement | 408 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 165.0 hp |
| Net Power | 165.0 hp |
| Aspiration | Turbocharged |
| Engine Make | Komatsu |
| Bore | 4 in |
| Stroke | 5 in |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 120 in |
| Length of Track on Ground | 206 in |
| Tail Swing Radius | 120 in |
| Width to Outside of Tracks | 107 in |
| Removal Counterweight Clearance | 43 in |
Undercarriage
| Track Gauge | 95 in |
|---|---|
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 46 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 240 in |
|---|---|
| Max Reach Along Ground | 362 in |
| Max Loading Height | 272 in |
| Max Vertical Wall Digging Depth | 215 in |
| Max Cutting Height | 386 in |
| Shipping Length of Unit | 385 in |
| Shipping Height of Unit | 130 in |
General Specifications
| Operating Weight lbs (kg) | 53,882 (24,440) Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 21.8 (6.62) Starting 2025 Model Year |
| Digging Reach ft. (m) | 32.4 (9.8) Starting 2025 Model Year |
| Engine hp (kW) | 165 (123) Starting 2025 Model Year |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 261 in |
|---|---|
| Max Vertical Wall Digging Depth | 236 in |
| Max Cutting Height | 395 in |
| Max Loading Height | 281 in |
| Max Reach Along Ground | 383 in |
| Shipping Length of Unit | 383 in |
| Shipping Height of Unit | 124 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 236 in |
|---|---|
| Max Cutting Height | 384 in |
| Max Loading Height | 271 in |
| Max Vertical Wall Digging Depth | 212 in |
| Max Reach Along Ground | 361 in |
| Shipping Length of Unit | 380 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 256 in |
|---|---|
| Max Cutting Height | 397 in |
| Max Reach Along Ground | 380 in |
| Max Loading Height | 283 in |
| Max Vertical Wall Dig Depth | 233 in |
| Shipping Length of Unit | 383 in |
