Kubota
New Holland
TC35
Tractor
21 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 2,624 lb |
|---|---|
| Fuel Capacity | 10.1 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 1,389 lb |
| 3 Point Hitch Type | Category 1 |
| Turning Radius | 100 in |
| Alternator Supplied Amperage | 40 A |
| Operating Voltage | 12 V |
| Tire Size Front - 2wd / 4wd | 7.2 - 16 |
| Cooling System Fluid Capacity | 1.6 gal |
| Lift Configuration | Position control |
Engine
| Engine Model | D1703-M-DI-E4 |
|---|---|
| Displacement | 100 in³ |
| Gross Power | 24.8 hp |
| Net Power | 23.9 hp |
| Number of Cylinders | 3 |
| Max Torque | 70 lb-ft |
| Engine Make | KUBOTA |
| PTO Power | 19.0 hp |
| Stroke | 4 in |
| Bore | 4 in |
| Engine Type | Direct injection Vertical Water-Cooled 4 cycle diesel |
| Rated Speed | 2,200 rpm |
Hydraulic System
| Pump Flow Capacity | 5.2 gal/min |
|---|---|
| system pressure | 2,205 psi |
| Implement Pump Flow PS | 3.2 gal/min |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 64 in |
| Overall Length | 106 in |
| Overall Width | 55 in |
| Height - Top of ROPS/FOPS | 93 in |
| Height | 59 in |
Transmission
| Max Speed | 11.5 mph |
|---|---|
| Number of Forward Gears | 3 |
| Transmission Type | Hydrostatic transmission 3 range speed |
| Number of Reverse Gears | 3 |
| Brakes | Wet disc type |
| Steering | Integral type power steering |
| Clutch, wet/dry | Dry type single stage |
Tires & Wheels
| Rear Tires Size | 11.2 - 24 |
|---|
