Kubota
New Holland
TC35
Tractor
21 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 2,601 lb |
|---|---|
| Fuel Capacity | 9.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 1,435 lb |
| 3 Point Hitch Type | Cat. I |
| Turning Radius | 100 in |
| Operating Voltage | 12 V |
Engine
| Engine Model | L2800HST |
|---|---|
| Displacement | 85 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 29.0 hp |
| Number of Cylinders | 3 |
| Aspiration | E-TVCS indirect injection |
| PTO Power | 22.5 hp |
Hydraulic System
| Pump Flow Capacity | 6.6 gal/min |
|---|
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 85 in |
| Wheelbase | 64 in |
| Overall Length | 9 in |
| Tire Size | front 7-16 rear 11.2-24 |
| Width Outside Frame | 52 in |
Transmission
| Max Speed | 13.7 mph |
|---|---|
| Transmission Type | Hydrostatic 3 range |
