Kubota
Branson
2400
Tractor
18 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 3,263 lb |
|---|---|
| Fuel Capacity | 10.6 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,646 lb |
| 3 Point Hitch Type | Cat. I |
| Turning Radius | 107 in |
| Alternator Supplied Amperage | 40 A |
| Operating Voltage | 12 V |
Engine
| Engine Model | L3130 GST |
|---|---|
| Displacement | 92 in³ |
| Power Measured @ | 2,700 rpm |
| Gross Power | 32.1 hp |
| Net Power | 31.0 hp |
| Number of Cylinders | 3 |
| Aspiration | E-TVCS indirect injection |
| PTO Power | 25.5 hp |
Hydraulic System
| Pump Flow Capacity | 13.3 gal/min |
|---|
Dimensions
| Ground Clearance | 14 in |
|---|---|
| Height - Top of Cab | 91 in |
| Wheelbase | 72 in |
| Overall Length | 10 in |
| Tire Size | front 7.2-16 rear 12.4-24 |
| Width Outside Frame | 60 in |
Transmission
| Max Speed | 16.6 mph |
|---|---|
| Number of Forward Gears | 12 |
| Transmission Type | GST |
| Number of Reverse Gears | 8 |
