Kubota
Branson
2400
Tractor
18 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 3,153 lb |
|---|---|
| Fuel Capacity | 11.7 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,646 lb |
| Turning Radius | 103 in |
| Alternator Supplied Amperage | 40 A |
| Operating Voltage | 12 V |
| Tire Size Front - 2wd / 4wd | 6.0-16 |
Engine
| Engine Model | E-TVCS |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 2,700 rpm |
| Gross Power | 34.0 hp |
| Net Power | 32.0 hp |
| Number of Cylinders | 3 |
| Aspiration | natural |
| PTO Power | 26.5 hp |
Hydraulic System
| Pump Flow Capacity | 13.3 gal/min |
|---|
Dimensions
| Wheelbase | 72 in |
|---|---|
| Overall Length | 10 in |
| Overall Width | 60 in |
| Height - Top of ROPS/FOPS | 97 in |
Transmission
| Max Speed | 16.6 mph |
|---|---|
| Number of Forward Gears | 8 |
| Transmission Type | FST |
| Number of Reverse Gears | 8 |
Tires & Wheels
| Rear Tires Size | 12.4-24 |
|---|
