Kubota
YTO
DFH-150
Tractor
13 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 3,384 lb |
|---|---|
| Fuel Capacity | 13.5 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,756 lb |
| 3 Point Hitch Type | Category 1 |
| Turning Radius | 107 in |
| Alternator Supplied Amperage | 40 A |
| Operating Voltage | 12 V |
| Tire Size Front - 2wd / 4wd | 8.3 - 16 |
Engine
| Engine Model | L4060DTRC |
|---|---|
| Displacement | 148 in³ |
| Gross Power | 42.0 hp |
| Net Power | 40.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Natural with EGR |
| Engine Make | KUBOTA |
| PTO Power | 34.0 hp |
| Bore | 4 in |
| Stroke | 4 in |
| Engine Type | E-TVCS indirect injection vertical liquid-cooled 4-cycle diesel |
| Rated Speed | 2,700 rpm |
Hydraulic System
| Pump Flow Capacity | 4.9 gal/min |
|---|---|
| Implement Pump Flow PS | 9.8 gal/min |
Dimensions
| Ground Clearance | 14 in |
|---|---|
| Wheelbase | 76 in |
| Overall Length | 122 in |
| Overall Width | 67 in |
| Height - Top of ROPS/FOPS | 98 in |
| Rear Tread Range | — |
| Front Tread Range | 46 in |
Transmission
| Number of Forward Gears | 8 |
|---|---|
| Transmission Type | FST |
| Number of Reverse Gears | 8 |
| Brakes | Wet disc type |
| Steering | Hydrostatic power steering |
| Clutch, wet/dry | Dry type single stage |
Tires & Wheels
| Rear Tires Size | 14.9 - 24 |
|---|
Power Take-Off (PTO)
| Power Take-Off(PTO) Type | Independent |
|---|---|
| Rear PTO | 1 speed: 540 rpm |
| Mid- PTO | 1 speed: 2000 rpm |
