Kubota
Yanmar
EF227H
Tractor
18 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 3,924 lb |
|---|---|
| Fuel Capacity | 13.5 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,976 lb |
| 3 Point Hitch Type | Category 1 & 2 |
| Turning Radius | 110 in |
| Alternator Supplied Amperage | 45 A |
| Operating Voltage | 12 V |
| Tire Size Front - 2wd / 4wd | 9.5 - 16 |
Engine
| Engine Model | L5060GSTRC |
|---|---|
| Displacement | 148 in³ |
| Gross Power | 52.0 hp |
| Net Power | 50.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Natural with EGR |
| Engine Make | KUBOTA |
| PTO Power | 44.0 hp |
| Stroke | 4 in |
| Bore | 4 in |
| Engine Type | E-TVCS indirect injection vertical liquid-cooled 4-cycle diesel |
| Rated Speed | 2,700 rpm |
Hydraulic System
| Pump Flow Capacity | 4.9 gal/min |
|---|---|
| Implement Pump Flow PS | 9.8 gal/min |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 76 in |
| Overall Length | 126 in |
| Overall Width | 69 in |
| Height - Top of ROPS/FOPS | 98 in |
| Rear Tread Range | — |
| Front Tread Range | 53 in |
Transmission
| Max Speed | 15.9 mph |
|---|---|
| Number of Forward Gears | 12 |
| Transmission Type | GST |
| Number of Reverse Gears | 8 |
| Brakes | Wet disc type |
| Steering | Hydrostatic power steering |
| Clutch, wet/dry | Dry type single stage |
Tires & Wheels
| Rear Tires Size | 14.9 - 26 |
|---|
Power Take-Off (PTO)
| Power Take-Off(PTO) Type | Independent |
|---|---|
| Rear PTO | 1 speed: 540 rpm |
| Mid- PTO | 1 speed: 2000 rpm |
