Kubota
L5240HSTC
- Operating Weight
- 4,233 lb
- Displacement
- 148 in³
- Power Measured @
- 2,600 rpm
- Gross Power
- 54.0 hp
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 4,233 lb |
|---|---|
| Fuel Capacity | 14.3 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,976 lb |
| 3 Point Hitch Type | Cat. I & II |
| Turning Radius | 110 in |
| Alternator Supplied Amperage | 55 A |
| Operating Voltage | 12 V |
Engine
| Engine Model | E-TVCS |
|---|---|
| Displacement | 148 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 54.0 hp |
| Net Power | 52.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| PTO Power | 45.0 hp |
Hydraulic System
| Pump Flow Capacity | 14.7 gal/min |
|---|
Dimensions
| Height - Top of Cab | 102 in |
|---|---|
| Wheelbase | 76 in |
| Overall Length | 11 in |
| Tire Size | front 9.5-16 rear 14.9-26 |
| Width Outside Frame | 69 in |
Transmission
| Max Speed | 15.5 mph |
|---|---|
| Number of Forward Gears | 3 |
| Transmission Type | HST plus 3 range |
| Number of Reverse Gears | 3 |
