Kubota
Ursus
2812
Tractor
28 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 7,981 lb |
|---|---|
| Fuel Capacity | 46.3 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 4,630 lb |
| 3 Point Hitch Type | Cat II |
| Turning Radius | 186 in |
| Alternator Supplied Amperage | 45 A |
Engine
| Engine Model | V3800-DT-TI |
|---|---|
| Displacement | 230 in³ |
| Power Measured @ | 2,600 rpm |
| Net Power | 108.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged w/ intercooler |
| PTO Power | 96.0 hp |
Hydraulic System
| Pump Flow Capacity | 17.2 gal/min |
|---|---|
| Number of Remote Control Valves | 1 |
Dimensions
| Height - Top of Cab | 106 in |
|---|---|
| Wheelbase | 96 in |
| Overall Length | 14 in |
| Tire Size | front 13.6-24 rear 18.4-34 Cast |
| Width Outside Frame | 91 in |
Transmission
| Number of Forward Gears | 16 |
|---|---|
| Transmission Type | fully synchronized |
| Number of Reverse Gears | 16 |
