Kubota
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 5,622 lb |
|---|---|
| Fuel Capacity | 20.1 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 3,307 lb |
| 3 Point Hitch Type | Rigid lower link easy adjust stabilizers / II |
Engine
| Power Measured @ | 2,400 rpm |
|---|---|
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Engine Make | Kubota |
| PTO Power | 61.0 hp |
| Engine Type | V3800-TIEF4 - Direct Injection water-cooled 4-cycle diesel Common Rail System Turbocharger Intercooler DPF DOC |
| Alternator | 130 A |
| Model Name | M4N-071HDRC12 |
| Rated Power | 72.6 hp |
Hydraulic System
| Pump Flow Capacity | 16.7 gal/min |
|---|---|
| Number of Remote Control Valves | 2 |
| Controls | Position draft (top link sensing) |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 91 in |
| Overall Width | 49 in |
Transmission
| Number of Forward Gears | 12 |
|---|---|
| Number of Reverse Gears | 12 |
| shuttle type | Electro-hydraulic |
Tires & Wheels
| Standard_Option_Front | 43,693 |
|---|---|
| Standard_Option_Rear | 12 – 24 |
Power Take-Off (PTO)
| PTO speed | 540 rpm |
|---|---|
| PTO type | Electro-hydraulic |
