Kubota
M5660SUHD
- Operating Weight
- 4,387 lb
- Displacement
- 148 in³
- Power Measured @
- 2,600 rpm
- Gross Power
- 57.9 hp
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 4,387 lb |
|---|---|
| Fuel Capacity | 17.7 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 3,307 lb |
| 3 Point Hitch Type | Category I & II |
| Turning Radius | 154 in |
Engine
| Displacement | 148 in³ |
|---|---|
| Power Measured @ | 2,600 rpm |
| Gross Power | 57.9 hp |
| Net Power | 56.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Engine Make | KUBOTA |
| PTO Power | 50.0 hp |
| Engine Type | 4 cylinder in-line Common Rail Sytem direct injection |
| Alternator | 45 A |
Hydraulic System
| Pump Flow Capacity | 10.6 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Controls | Position |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 80 in |
| Overall Length | 136 in |
| Overall Width | 74 in |
| Height - Top of ROPS/FOPS | 95 in |
| Rear Tread Range | 68 in |
| Front Tread Range | 55 in |
Transmission
| Max Speed | 18.6 mph |
|---|---|
| Number of Forward Gears | 8 |
| Number of Reverse Gears | 8 |
| Clutch, wet/dry | Multiple wet disk |
| Differential lock | Rear standard (mechanical) |
| Brake type | Mechanical wet disc |
| shuttle type | Hydraulic shuttle |
Tires & Wheels
| Standard_Option_Front | 8 – 24 |
|---|---|
| Standard_Option_Rear | 15 – 28 |
Power Take-Off (PTO)
| PTO speed | 540 rpm |
|---|---|
| PTO type | Live-independent hydraulic PTO |
