Kubota
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 4,189 lb |
|---|---|
| Fuel Capacity | 17.7 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 3,307 lb |
| 3 Point Hitch Type | Category I & II |
Engine
| Engine Model | V2403-CR-TE4 |
|---|---|
| Displacement | 148 in³ |
| Net Power | 56.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| PTO Power | 50.0 hp |
| Engine Type | 4 cylinder in-line Common Rail Sytem direct injection |
| Alternator | 45 A |
| Air cleaner | Dry dual element |
| Model Name | M5660SUHRC |
| Rated Power | 57.9 hp |
Hydraulic System
| Pump Flow Capacity | 10.6 gal/min |
|---|---|
| Number of Remote Control Valves | 1 |
| Controls | Position |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 83 in |
| Overall Length | 139 in |
| Overall Width | 74 in |
| Height - Top of ROPS/FOPS | 96 in |
| Rear Tread Range | 68 in |
| Front Tread Range | 72 in |
Transmission
| Max Speed | 18.6 mph |
|---|---|
| Number of Forward Gears | 8 |
| Number of Reverse Gears | 8 |
| Differential lock | Rear standard (mechanical) |
| Brake type | Mechanical wet disc |
| Clutch disk diameter wet clutch | — |
| Shuttle (Forward-Reverse) | Hydraulic shuttle |
Tires & Wheels
| Standard_Option_Front | 7 – 16 |
|---|---|
| Standard_Option_Rear | 15 – 28 |
Power Take-Off (PTO)
| Power Take-Off(PTO) Type | Live-independent hydraulic PTO with PTO brake multi-plate wet clutch |
|---|---|
| PTO speed | 540 rpm |
