Kubota
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 3,792 lb |
|---|---|
| Fuel Capacity | 17.2 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 3,307 lb |
| 3 Point Hitch Type | Cat I with Cat II link ends |
| Turning Radius | 115 in |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 2.0 gal |
| Engine Oil Capacity | 2.2 gal |
Engine
| Engine Model | EF2803-EA |
|---|---|
| Displacement | 168 in³ |
| Power Measured @ | 2,800 rpm |
| Net Power | 57.0 hp |
| Number of Cylinders | 4 |
| PTO Power | 52.0 hp |
Hydraulic System
| Pump Flow Capacity | 17.1 gal/min |
|---|
Dimensions
| Ground Clearance | 14 in |
|---|---|
| Wheelbase | 79 in |
| Overall Length | 11 in |
| Tire Size | front 8.0-16 R1 rear 12.4R24 radial |
| Width Outside Frame | 43 in |
Transmission
| Number of Forward Gears | 12 |
|---|---|
| Transmission Type | fully synchronized |
| Number of Reverse Gears | 12 |
Axles
| Final Drive | inboard planetary |
|---|
