Kubota
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating Weight | 5,027 lb |
|---|---|
| Fuel Capacity | 18.5 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 3,307 lb |
| Turning Radius | 143 in |
Engine
| Engine Model | V3307-CR-TE4 |
|---|---|
| Displacement | 203 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 71.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Engine Make | Kubota |
| PTO Power | 64.0 hp |
| Engine Type | 4 cylinder in-line Common Rail System direct Inject. |
| Alternator | 45 A |
| Model Name | M7060 |
Hydraulic System
| Pump Flow Capacity | 11.0 gal/min |
|---|---|
| Number of Remote Control Valves | 1 |
| Hydraulic System Type | Telescopic lower link ends Telescopic Stabilizers |
| Controls | Position draft (top link sensing) & mixed control |
| Hydraulic cylinders Type | Two external cylinders |
Dimensions
| Wheelbase | 83 in |
|---|---|
| Overall Length | 138 in |
| Overall Width | 74 in |
| Height - Top of ROPS/FOPS | 97 in |
| Rear Tread Range | 68 in |
| Front Tread Range | 60 in |
| Crop clearance | 18 in |
Transmission
| Number of Forward Gears | 8 |
|---|---|
| Transmission Type | HD |
| Number of Reverse Gears | 8 |
| Clutch, wet/dry | Multiple wet disk |
| Differential lock | Limited Slip Differential / Mechanical |
| Brake type | Mechanical wet disc |
| shuttle type | Hydraulic-shuttle |
Tires & Wheels
| Standard_Option_Front | 10 – 24 |
|---|---|
| Standard_Option_Rear | 17 – 30 |
Power Take-Off (PTO)
| PTO speed | 540 rpm |
|---|---|
| PTO type | Live -independent PTO electro-hydraulic clutch with brake |
