Kubota
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 4,079 lb |
|---|---|
| Fuel Capacity | 15.9 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 3,307 lb |
| 3 Point Hitch Type | Cat I with Cat II link ends |
| Turning Radius | 126 in |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 2.4 gal |
| Engine Oil Capacity | 2.9 gal |
Engine
| Engine Model | V3300-TE |
|---|---|
| Displacement | 202 in³ |
| Power Measured @ | 2,600 rpm |
| Net Power | 82.0 hp |
| Number of Cylinders | 4 |
| Aspiration | E-TVCS liquid cooled |
| PTO Power | 73.0 hp |
Hydraulic System
| Pump Flow Capacity | 17.1 gal/min |
|---|
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 89 in |
| Wheelbase | 79 in |
| Overall Length | 11 in |
| Tire Size | front 8.0-16R1 rear 12.4R24 radial |
| Width Outside Frame | 41 in |
Transmission
| Number of Forward Gears | 12 |
|---|---|
| Transmission Type | fully synchronized |
| Number of Reverse Gears | 12 |
Axles
| Final Drive | inboard planetary |
|---|
